Sea-Dog Waterproof Heavy Duty Wiper Motors - 110D 1.5"

Waterproof Heavy Duty Wiper Motors are a two-speed, self-parking motor for exterior/unprotected locations. Sweep angle is preset at 80° or 110°, but can be reset to 40°, 50°, 60°, 70°, 80°, 90°, or 110°.

Adjustable right or left-hand park, factory preset for left-hand park. Powers up to a 24” arm and blade configuration (36” total length). Constructed of powder coated aluminum housing with stainless steel mounting bracket, shaft, and knurled fitting. Available in black or white, 12VDC or 24VDC (white only). IP66 rating. CE compliant. 3-year warranty.

Technical Specifications

• Shaft Parameters: Features a 1.5-inch shaft length with a 5/8-inch diameter and a knurled stainless steel drive fitting.
• Sea-Dog Waterproof Heavy Duty Wiper Motors - 110D 1.5" Pre-set Sweep: Factory pre-set to a 110° sweep angle. The sweep is adjustable and can be mechanically reset to 40°, 50°, 60°, 70°, 80°, or 90°.
• Power Capability: Heavy-duty internal gearing powers up to a 24-inch arm and blade configuration, achieving a maximum total clearing length of 36 inches.
• Electrical Rating: Engineered for 12V DC marine systems drawing approximately 2 Amps.
• Ingress Protection: Carries an IP66 rating, making it completely dust-tight and resistant to strong waves or high-pressure water jets.

• Corrosion Resistance: Built using a powder-coated die-cast aluminum housing paired with a 304 stainless steel mounting bracket and drive shaft.
• Self-Parking Function: Utilizes a "coast-to-park" feature that ensures the blade cleanly returns to the side of the window when turned off. It is factory pre-set for left-hand park but easily adjusts for right-hand park.
• Footprint Compatibility: Designed with a mounting pattern that drops directly into the footprint of most industry-standard heavy-duty marine wiper motors.

Model Variations

• Sea-Dog 412211B-3: Finished in a matte black powder coat.
• Sea-Dog 412211W-3: Finished in a gloss white powder coat.
