Description
Heavy Duty In-Line Fuse Holder
The Blue Sea Systems 5063 Heavy Duty Inline Fuse Holder is a compact electrical safety component engineered to provide overcurrent and short-circuit protection in harsh marine and automotive environments.
Blue Sea 5063 Heavy Duty Inline Fuse Holder AGC/MDL Specifications
- Maximum Amperage: 30 Amps
- Maximum Voltage: 32V DC
- Compatible Wire Gauges: 12 to 18 AWG
- Wire Style: Supplied with tinned copper 12 AWG pigtails for excellent corrosion resistance
- Compatible Fuse Types: Standard glass 1/4" x 1-1/4" fast-acting AGC or time-delay MDL fuses (fuses are sold separately)
- Contact Material: High-conductivity brass
Applications
This heavy-duty inline holder is typically spliced directly into a positive DC power line close to the power source. It is used to protect individual electronic devices, secondary battery banks, switching panels, or local loads from power surges and electrical faults.
Specifications
- Fuse Type:
- AGC/MDL
- Type:
- Fuse Holders
