Description
The Blue Sea Systems 5018 ST Glass Fuse Block is a heavy-duty, marine-grade solution for consolidating branch circuits and in-line glass fuses. This specific model does not feature an integrated negative bus, meaning it is designed solely for distributing positive power, making it ideal for systems with centralized or separate common ground points. [1,
Technical Specifications
- Circuits: 6 independent circuit positions
- Amperage Rating: Maximum 30A per circuit | Maximum 100A per block total
- Voltage Rating: Maximum 32V DC (suitable for 12V and 24V applications)
- Fuse Compatibility: Accepts 1/4" x 1-1/4" (3AG) glass fuses, including AGC (fast-acting) and MDL (time-delay) from 1/8A to 30A
- Terminals: #8-32 screw terminals featuring captive star lockwashers for robust wire connections
- Mounting: Uses #10 screws (or #8 M4 screws)
Benefits
- Premium Conductivity: Features a removable positive bus made of tin-plated copper alongside phosphor bronze fuse clips to provide exceptional corrosion resistance and a firm hold on glass fuses.
- Safety & Storage Cover: Includes a clear polycarbonate insulating cover that encapsulates all conductive parts, meeting strict ABYC and USCG safety requirements. The cover also features built-in storage slots for spare fuses and dedicated recesses for large-format labels.
- Ease of Use: Equipped with an integrated fuse ejector lever, solving the common struggle of prying tight glass fuses out of their clips.
Specifications
- California Residents:
- WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.
- Fuse Type:
- AGC/MDL
- Type:
- Fuse Blocks
